4-Port USB 3.1 Over Cat6a Extender
#29523
C2G
4-Port USB 3.1 Over Cat6a Extender is rated
out of
5 by
1.
Bazaarvoice SAP Hybris Integration Version 2.8.1
$2,615.99 $2,905.99 MSRP USD
The 4-Port USB 3.1 Over Cat6a Extender was designed to extend USB 3.1, 2.0 and 1.1 devices simultaneously up to 328 feet over a single Cat6a cable, making it a perfect solution for USB 3.1 conferencing cameras, interactive white boards, security and monitoring, video matrix systems, remote storage, and/or any other USB 3, 2 and 1 device.
Convenience
No software drivers required, making installation quick and easy with true plug and play convenience. Simply connect the Transmitter to the source computer, extend with a single category cable, and connect the Receiver to as many as four USB devices.
Performance
The 4-Port USB 3.1 Over Cat6a Extender provides the ability to connect USB 3.1 Gen 1 (5 Gbps) device types and is backwards compatible to USB 2.0 and 1.1 across a point-to-point connection. The extender also includes an Ethernet pass-through for connecting to network enabled devices or to use existing infrastructure without losing LAN connectivity.
Convenience
No software drivers required, making installation quick and easy with true plug and play convenience. Simply connect the Transmitter to the source computer, extend with a single category cable, and connect the Receiver to as many as four USB devices.
Performance
The 4-Port USB 3.1 Over Cat6a Extender provides the ability to connect USB 3.1 Gen 1 (5 Gbps) device types and is backwards compatible to USB 2.0 and 1.1 across a point-to-point connection. The extender also includes an Ethernet pass-through for connecting to network enabled devices or to use existing infrastructure without losing LAN connectivity.
Connector 1:
(1) USB 3.0 B Female, (2) RJ-45 Female
Connector 2:
(4) USB-A Female, (2) RJ-45 Female
Quantity
108 In Stock
- Send
- Save as PDF
-
Added to Favorites Go to favoritesRemove from favorites?Something went wrong. Please try again later.
Features
- USB 3.1 Gen 1 data rate up to 5 Gbps
- Integrated four port USB 3.1 hub
- Supports all USB 3.1, 2.0, 1.1 devices simultaneously at full bandwidth
- Up to 1.2A (6W) per USB port
- 100/1000 Mbps Ethernet channel
- LAN pass-through
- Point-to-point connection
- Requires a single Cat6a cable
- Plug and Play—no driver required
Specifications
General Info
| Product Line | C2G | ||
| Color | Black | ||
| UPC Number | 757120295235 | ||
| Country Of Origin | China | ||
| Application Sector | Commercial, Residential | ||
| Warranty Type | 5-Year | ||
| Type | Active Device, Extender, Kit |
Dimensions
| Product Width US | 9.1 in | ||
| Product Height US | 1.3 in | ||
| Product Length US | 5.4 in |
Technical Information
| Jacket Material | PVC (Polyvinyl Chloride) | ||
| Data Transfer Rate | 5 Gbps |
Resources
Cutsheet
Data Sheet
Reviews
Rated 5 out of
5
by
Jfreeman from
So far, it works well
Bought this 2 weeks ago. We have a 4K USB 3.1 camera running over about 75ft of Cat6a solid-copper cable. So far, we have noticed no hiccups.
The two units do seem to get warm. They won't burn you, but it's like a laptop that gets fairly warm. I hope this doesn't reduce its reliability over time.
Date published: 2020-10-11
